原相科技PS5250 CMOS SENSOR产品规格

深圳市绿都电子有限公司是台湾原相科技的代理商,欢迎来电垂询,联络电话:0755-83777478、18688790400。


General Description

The PS5250 is a low power, highly integrated CMOS image sensor that output of 1920x1080 (Full HD-1080p)pixels with rolling shutter readout. It embedded the new FinePixel™ sensor technology to perform the excellentimage quality. PS5250 outputs 10-bit RGB raw data through a parallel digital video port or via serial MIPIinterface through one-lane or dual-lane transmission. It is available in CSP package only.The PS5250 can be programmed to set the exposure time for different luminance condition via I2CTM serialcontrol bus. By programming the internal register set, it performs on-chip black level correction and hightemperature image quality control.


Features
1928 x 1088 pixels with Bayer-RGB color filter array and micro-lens
Output format:
    - 10bit RAW RGB
Output interface
    - 10bit parallel DVP output
    - dual-lane serial MIPI CSI2 output (up to 800Mbps per lane)
 On-chip column A/D converter
 On-chip manual analog gain control
 Continuous variable frame time & exposure time
 I2CTM Interface
 Automatic black-level calibration
 Black sun cancellation
 Support WOI and subsampling
 Support dummy line & pixel timing
 Support output Hsync at Vsync
 Support sensor frame synchronization
 Support 1.6V~3.6V I/O
On-chip PLL

(input_clock / PLL_m >= 1MHz)
